3.5 metric ton mini excavator

Engine

• Output (SAE J1995 gross) ……………….………. 16.1 (12.0) / 2300 HP (kW)/rpm
• Output (SAE J1349 net) …….…………….….….. 15.1 (11.3) / 2300 HP (kW)/rpm
• Displacement …………………………….…..……. 54.8 (898) cu.in. (cc)

Dimensions

• Overall length …………………….………..…….…. 11’7″ (3545) ft.in. (mm)
• Overall height ……………………………………….. 7’8″ (2340) ft.in. (mm)
• Overall width ………………………………………… 3’3″ (990) / 4’1″ (1240) ft.in. (mm)
• Min. ground clearance ………………….…..……… 5.9″ (150) in. (mm)

Hydraulic System

• Pump capacity ……………………………….… 4.57 (17.3) × 2 / 2.75 (10.4) × 1 GPM
• Auxiliary hydraulic flow ………………………… 7.32 (27.7) GPM
• Max. breakout force Bucket / Arm ………….… 3417.2 (1550) / 1918 (870) lbs. (kgf)

Drive System

• Travel speed Low / High …………….……………… 1.4 (2.2) / 2.6 (4.0) mph (km/h)
• Max. traction force ………………………….……….. 4865 (2207) lbs. (kgf)
• Tumbler distance …………………….………………. 4’0″ (1230) ft.in. (mm)
• Crawler length ………………………………..…..….. 5’2″ (1585) ft.in. (mm)
• Shoe width ……………………………………….…… 9.1″ (230) in. (mm)
• Ground contact pressure ……………………….…… 3.8 (0.27) psi (kgf/cm2)

Swing System

• Unit swing speed …………………………….………… 9.1 rpm
• Boom swing angle Left / Right ……………..………… 65 / 58 degree

Blade

• Width …………………………………………..….… 4’1″ (1240) / 3’3″ (990) ft.in.(mm)
• Height …………………………………………..…… 10.3″ (260) in. (mm)
• Max. lift above ground ………………………………..… 11.0″ (280) in. (mm)
• Max. drop below ground …………….…………………… 7.5″ (190) in. (mm)

Hydraulic oil (reservoir/system) …………………….….…… 3.4 (13) / 6.1 (23) gal
Fuel reservoir …………………………………………….…… 5.02 (19) gal
Operating weight (Including operator’s weight 175 lbs.) …. 3703 (1680) lbs.(kgf)
