100 HP tractor

Engine

• Engine hp, gross ……………………..………………………….. 105.6 hp @ 2400 rpm
• Engine hp, net …………………….….…………..………………. 100.0 hp @ 2400 rpm
• Engine hp, PTO ………………….….…………..……………..….. 89.0 hp @ 2400 rpm
• Maximum torque ……………….….……………..……… 263 ft. lbs. @ 1400-1600 rpm
• Bore and Stroke ………………..….……….………………..…………. 3.94 in. x 4.72 in
• Displacement ………………….………………………….…………………. 230 cu. Inch
• Fuel per hour ……………….…………….……………………….. 3.85 gal @ 75% load
• Cylinder Block …………….……………………………………. Parent Bore (linerless)
• Fan ……………………….….…………………………….…………..…. Fixed fan drive
• Air Cleaner Element …………… Dry Paper/Dual Element, 8″ diameter, Pre-Cleaner
• Cold Weather Start Aid ……………………………. Auto.preheat with PTC intake heater
• Lubrication ………………………………………………..…………. Forced Lubrication
• Governor ……………………….………………….………….. Electronic type governor
• Injection pump ………………..……….……. Electronic CRS (Common Rail System)
• Fuel filter system .. 1-Spin on type fuel filter with water separator w/man. drain cock
• Oil filter ………………………………………………………………….. Spin on oil filter
• Exhaust …………….…. DPF and SCR Under Hood Pipe up or Down Exhaust Pipe
• Throttle …………………..…………………..…………. Hand and foot operated throttle

Cooling System

• Radiator ………………………… Heavy duty pressurized radiator with recovery tank
• Water pump ………………………………………………..……….. Positive water pump

Capacities

• Fuel Tank/ DEF Tank …………………………………..……..…………….. 27.7/3.2 gal
• Cooling System ……………………………………………………………….………………….……… 11 qt
• Engine Oil …………………………………………………………………….……. 11.3 qt
• Transmission …………………………………………………………. 63.4 qt. (17.2 gal.)
• Front Axle ……………..… 6.3 (Differential) plus 3.7 qt. (per each Bevel Gear Case)
• Washer fluid (windows) …………………………………………………..……… 1.4 qt.

AXLE LOAD RATINGS (Maximum)

• Front Axle 2WD lbs ……………………………………………… 4850 @ 56.7” tread spacing
• Front Axle 4WD lbs ……………………………………….……5,730 @ 62.2” tread spacing
• Rear Axle lbs ………………………………………………8,160 @ 60.2” tread spacing
